Light Source
- Type: Main: RGBL | FX Layer: RGBW (32 pixels)
- Count: Main: 1 | FX Layer: 32 LEDs in 3 rings
- Power: Main: 150 W
- Light Source Lifetime: 50,000 h
Optical System
- min. Zoom: 4.6°
- max.Zoom: 34°
- Front Lens: Single Micro-Fresnel, diameter: 165 mm
Dynamic Effects
- Dimmer / Shutter: 0 – 100%, 16 bit
Control and Programming
- DMX Channels: 18 | 28 | 40 | 52 | 171 | 427
- Control Modes: 6
- Protocols: DMX (USITT DMX512-A) | RDM (ANSI/ESTA E1.20) | GLP iQ.Mesh
- High-Res Channels: Dimmer | Tilt | Pan
- Dimming Curves: linear | soft | S-Curve
- Performance Modes: Fast | Normal (Balanced) | Smooth
- Fan Modes: regulated | high | medium | low
- Setting & Addressing: backlit graphic LCD | 4 Button Menu Navigation | DMX | RDM | GLP iQ.Mesh | 1 Scene Stand Alone
- Other Control Options: 3 Layer Pattern-FX-Engine
- Software Update: GLP iQ.Mesh | GLP iQ.Tool | GLP iQ.Control App
Connections
- Power Connection: Neutrik powerCON TRUE1 In/Out
- Signal Connection: Neutrik XLR 5-Pin In/Out
Construction
- Housing Color: Black
- Housing Material: high-impact flame-retardant thermoplastic | aluminum
- Protection Rating: IP20
Electrical Specifications
- Power Input: 100 – 240 VAC / 50 – 60 Hz
- Power Supply Unit: auto-ranging electronic switch-mode
- max. Power (@ 230 V): 200 W
- Fuse: T4A 250V 5x20mm
Installation
- Mounting: 1 pair of 1/4-turn locks | 2 eyelets for safety cable
- Orientation: any
- Location: Dry| Indoor Temporary
- min. Distance to Combustible Materials: 0.1 m
- min. Distance to Illuminated Surfaces: 1.0 m
Movement
- Pan: continuous 540°, 16 bit
- Tilt: 208°, 16 bit
Thermal Specifications
- Cooling: combined convection and forced air
- Overheating Protection: automatic
- min. Ambient Temperature: 5 °C / 40 °F
- max. Ambient Temperature: 45 °C / 113 °F
Approvals & Classifications
- Risk Group EN 62471: Risk Group 2
Dimensions & Weight
- Height: 311 mm / 12.24 in
- Height (head straight up): 354 mm / 13.93 in
- Width (across yoke): 250 mm / 9.84 in
- Depth (head straight up): 185 mm / 7.28 in
- Weight (netto): 5.2 kg / 11.46 lbs
