volkslicht spot

The GLP VolksLicht Spot features a 300 Watt RGB LED engine, offering high output through an efficient optical system with clear gobo projection, as well as an even field distribution, and smooth dimming without any color shift, all in a spot fixture format.

The Volkslicht Spot features near silent operation and is designed for venues and events keen to embrace the low maintenance and easy operational aspects of leading edge LED technology.

The feature set of the GLP VolksLicht includes a motorized iris, rotating gobo wheel with 7 positions plus open, a static gobo wheel with 9 positions plus open. Additionally, a rotating prism and motorized focus are included within the small body, allowing the fixture to be placed discretely. The output features a beam angle of 15° degrees. With a light weight of just 33 lbs., it has been designed for permanent installations or for applications with shorter throw distances than the award winning GLP impression Spot One.



Contact us for more information on the Volkslicht Spot
Want to stay up to date with the latest from GLP?
Click the link here to sign up for GLP’s mailing lists


Light Source

  • 300 Watt RGB LED chipset
  • Average service life: 20,000 hours

Optical System

  • Fixed beam angle: 13°
  • Motorized focus: 2m – infinity
  • Full red, green and blue additive color mixing system


  • 8 or 16 bit resolution selectable
  • 540° pan / 280° tilt
  • Position feedback
  • High precision 3 phase stepper motor control


  • USITT DMX 512 protocol
  • Over temperature protection
  • Very quiet temperature controlled ventilation system
  • Backlit graphic LCD menu
  • Internal color presets and variable color temperature control from 2500 Kelvin to 10,000 Kelvin

Electromechanical Effects

  • Gobo wheel 1: 7 gobos +open, rotating and indexable, interchangeable
  • Gobo wheel 2: 9 gobos +open, fixed
  • Iris closes down to 4%
  • Rotating prism and indexable interchangeable 3-facet prism
  • Smooth electronic dimming 0-100%
  • Electronic high-speed shutter 0-10 Hz


  • Outside diameter: 23 mm
  • Image diameter: max. 19 mm
  • Thickness for aluminum gobos: 0.5 mm
  • Thickness for glass gobos: 1.1 – 3 mm

Power Supply

  • Power consumption: max. 400 (Watt)
  • Power input: auto sensing 100-240V AC, 50-60 Hz
  • Fuse protection


  • DMX data: XLR 5 pin in/out
  • DMX data: XLR 3 pin in/out
  • Neutrik Powercon in/out

Operating Conditions

  • Maximum ambient temperature: 113°F (45°C)

Mounting Options

  • M10 sockets for half coupler or other clamp
  • Any orientation


  • Cardboard box
  • 4-way tour pack (complete with half couplers) in flight case

Housing Colors

  • Standard color is black
  • For other colors please contact sales department


  • (L x W x H): head vertical
    •   11.25  in. x 12.5 in. x 21.2 in.  (28.6 cm x 31.8 cm x 53.8 cm)

Net weight

  • 33 lbs. (15 kg)
