FUSION by GLP’s Exo Spot is a powerful IP65 rated moving head with a white light LED and a zoom of 7° to 30°, with gobos, CMY color mixing, prism, and frost in a compact housing with bright output.

FUSION by GLP’s Exo Spot is an IP65 rated moving head with a powerful output that can generate sharp images that can be seen for long distances.

The Exo Spot features a single, powerful and highly efficient 230 W, 7500 Kelvin white light LED engine.

The Exo Spot features a zoom range from a tight 7° out to 30° along with incredibly fast pan and tilt movements, combining to give incredible mid-air effects – either indoor, or out.

The Exo Spot fixture comes equipped with a range of additional effects, including a three way rotating prism, two gobo wheels with both static and rotating gobos, three color wheels, frost filter, prism, and CMY color mixing.

The versatile fixture can operate anywhere in the world and in any orientation with wireless DMX control available as an optional extra. It features a robust die cast housing, which combined with the IP65 rating make the Exo Spot ready for even the worst of outdoor conditions.





Contact us for more information on the Exo Spot
Want to stay up to date with the latest from GLP?
Click the link here to sign up for GLP’s mailing lists

Light Source

  • 1x 230 W White LED, rated at 7500 Kelvin
  • 20,000 lifetime hours



Control

  • DMX 512
  • 4 button OLED display



Effects

  • 3 color wheels each with 6 dichroic filters, plus open
  • 2 ‘Hybrid’ gobo wheels with 6 rotating and 8 fixed gobos
  • 3 way rotating Prism
  • 16 bit pan (540°) / tilt (258°) movement, with position feedback
  • Magnetic head mounts
  • Anti-fog system



Connectors

  • XLR 5-pin in and out
  • Neutrik TRUE1 power input and thru



Power

  • Auto sensing 100-240 VAC / 50-60 Hz
  • Neutrik TRUE1 in and out
  • 295 W (max.)



Optical System

  • Focus: 6.56 ft – infinite
  • Zoom: 7° to 30°
  • 4.33 in. Lens Diameter



Mounting Options

  • 2 pairs of 1/4 turn locks
  • Safety wire attachment point
  • Built in rubber feet
  • Operates in any orientation



Thermal Specifications

  • Max. ambient temperature 113°F (45°C)
  • Min. ambient temperature -4°F (-20°C)



Dimensions

  • L x W x H
    • 14.5 in. x 15.96 in. x 23.8 in.
    • 36.8 cm x 38 cm x 60.5 cm



Net Weight

  • 56.2 lbs (25.9 kg)

User Manual

PDFIcon EXO Spot User Manual EN Rev B

PDFIcon EXO Spot DMX Channel Index EN Rev B

CAD

EXO Spot CAD

Fixture Libraries

ZIPIcon Exo Spot 30 MA

Specifications

PDFIcon PDF Exo Spot Cut Sheet

PDFIcon PDF Exo Spot Data Sheet
