Exo Beam White LED Light – Stage lighting Products GLP

FUSION by GLP’s Exo Spot is an IP65 rated moving head with a powerful output that can generate sharp images that can be seen for long distances.

The Exo Spot features a single, powerful and highly efficient 230 W, 7500 Kelvin white light LED engine.

The Exo Spot features a zoom range from a tight 7° out to 30° along with incredibly fast pan and tilt movements, combining to give incredible mid-air effects – either indoor, or out.

The Exo Spot fixture comes equipped with a range of additional effects, including a three way rotating prism, two gobo wheels with both static and rotating gobos, three color wheels, frost filter, prism, and CMY color mixing.

The versatile fixture can operate anywhere in the world and in any orientation with wireless DMX control available as an optional extra. It features a robust die cast housing, which combined with the IP65 rating make the Exo Spot ready for even the worst of outdoor conditions.

Contact us for more information on the Exo Spot
Want to stay up to date with the latest from GLP?
Click the link here to sign up for GLP’s mailing lists

Light Source

1x 230 W White LED, rated at 7500 Kelvin
20,000 lifetime hours

Control

DMX 512
4 button OLED display

Effects

3 color wheels each with 6 dichroic filters, plus open
2 ‘Hybrid’ gobo wheels with 6 rotating and 8 fixed gobos
3 way rotating Prism
16 bit pan (540°) / tilt (258°) movement, with position feedback
Magnetic head mounts
Anti-fog system

Connectors

XLR 5-pin in and out
Neutrik TRUE1 power input and thru

Power

Auto sensing 100-240 VAC / 50-60 Hz
Neutrik TRUE1 in and out
295 W (max.)

Optical System

Focus: 6.56 ft – infinite
Zoom: 7° to 30°
4.33 in. Lens Diameter

Mounting Options

2 pairs of 1/4 turn locks
Safety wire attachment point
Built in rubber feet
Operates in any orientation

Thermal Specifications

Max. ambient temperature 113°F (45°C)
Min. ambient temperature -4°F (-20°C)

Dimensions

L x W x H
- 14.5 in. x 15.96 in. x 23.8 in.
- 36.8 cm x 38 cm x 60.5 cm

Net Weight

56.2 lbs (25.9 kg)

User Manual

FUSION Exo Spot User Manual EN Rev D[3]

FUSION Exo Spot DMX Channel index EN Rev D[3]

CAD

FUSION EXO Spot CAD Rev20230310-1

FUSION EXO Spot Vectorworks Rev20230310-1

Fixture Libraries

FUSION Exo Spot MA2 Fixture File

Photometrics

FUSION Exo Spot Photometrics

Specifications

PDF Exo Spot Cut Sheet

PDF Exo Spot Data Sheet
