Scenex Lighting distributes a wide range of LED tape and product solutions. From single color to full RGB(WW)CW color mixing, indoor and outdoor IP rated needs, flexible and fixed variants, we’ve got hundreds of solutions for your customization.

The Warm White LED Tape from Scenex Lighting is IP65 rated, and and can be trimmed to any custom size as required, providing a versatile lighting platform for indoor and outdoor lighting designs.

Scenex also offer a range of different power supply and DMX drive options, including Artnet integration for larger systems.

We are happy to consult and advise on any system design. Free of charge and without obligation, in order to help support and make your vision become a reality.



Contact us for more information on the Warm White LED Tape
Want to stay up to date with the latest from Scenex?
Click the link here to sign up for Scenex’s mailing lists

Part Number
Color Warm white Warm white Warm white
Wavelength n/a n/a


Color temp 2800K-3200K 2800K-3200K 2800K-3200K
Lumens pr. mtr. / pr strip 720 / 2160 360 / 1080 360 / 1800
LED’s pr mtr / pr strip 60 / 180 30 / 90 30 / 150
LED type SMD 5050 SMD 5050 SMD 5050
Field angle 120° 120° 120°
Housing material Flexible strip with silicone covering Flexible strip with silicone covering Flexible strip with silicone covering
Color White White White

Protection rating

IP 65 IP 65 IP 65

Adhesive backing

Adhesive backing

Adhesive backing

Wiring connection 2 cable tail (V-, V+) 2 cable tail (V-, V+) 2 cable tail (V-, V+)
Power voltage 12V 12V 12V
Current pr mtr. / pr strip 14.4W / 43.2W

7.2W / 21.6W

7.2W / 36W
Energy saving class Class A Class A Class A
Operating temp.

   5°F   –  104°F
(-15°C   –  40°C)

23°F  –  104°F
  (-5°C  –  40°C)

23°F   –  104°F
  (-5°C   –  40°C)

Cutting possibility Every 1.9″  (5 cm) Every 3.9″  (10 cm) Every 3.9″  (10 cm)
Dimensions – inches

L x W x H
118.1″ x 0.4″ x 0.1″

L x W x H
118.1″ x 0.5″ x 0.1″

L x W x H
196.8″ x 0.47″ x 0.1″

Dimensions – centimetres

L x W x H
300 cm x 1.0 cm x 0.3 cm

L x W x H
300 cm x 1.2 cm x 0.3 cm

L x W x H
500 cm x 1.2 cm x 0.3 cm

Data Sheet

PDFIconScenex Lighting LED Tape

PDFIcon Scenex Lighting LED Tape Riser Diagram
